HERO Achiever - HANDLEBAR CONTROLS; Left Handlebar Controls; Right Handlebar Controls

LEFT HANDLEBAR CONTROLS
RIGHT HANDLEBAR CONTROLS
14
1
2
5
5. Passing Lamp Switch
Gives an indication for passing ahead.
Press passing lamp switch (5) to operate the
passing lamp
6. Clutch Switch
There is a clutch switch (6) provided for the
safety of the rider. The motorcycle cannot be
started by electric starter switch until the clutch
lever is operated when the vehicle is engaged
in gear.
1. Headlamp Dimmer switch
The headlamp operates only when the engine
is running or when passing switch is operated.
Select “ ” for high beam and “ ” for low
beam.
2. Turn Signal Switch ( )
Shift the turn signal switch sideways for
right/left indications and leave it to come back
to its normal position on its own.
IMPORTANT : To switch “OFF” the turn
signal after completing the turn, gently push
the switch inside as directed on the switch.
3. Horn Switch ( )
Press the switch to operate the horn.
4. Bystarter Lever ( )
To apply bystarter, pull the lever (4)
downwards, towards the rider, as directed on
the switch.
NOTE
Do not accelerate during starting when the
bystarter is on.
1
2
3
4
6
