STEERING LOCK
i3s (IDLE STOP START SYSTEM)
Starting & Warm up the engine:
Keep the i3s switch (1) to “OFF” position.
Turn the ignition key to “ON” position. the
i3s indicator (2) will glow on the speedometer
console for 2 seconds and turn “OFF”. Start
the engine and let it idle for 2-3 minutes.
15
î Never hold electric starter switch continuously
more than 5 seconds as continuous cranking
of engine will drain the battery.
î During electric or clutch start, the engine will
cut-off if engine reaches 900 rpm if the
relay is engaged for more than 5 seconds.
CAUTION
!!
1. Electric starter switch ( )
Ensure starter switch ( ) is operated when the 1
vehicle is in neutral gear. If the vehicle is
engaged in gear, press the clutch lever before
operating the starter switch. Release starter
switch after the engine has started.
2. i3s Switch
There is an i3s switch provided to enable (2)
the rider for turning i3s mode “ON” or “OFF”
based on the traffic conditions.
(1) i3s switch
Steering lock is with ignition switch. Turn the
key (1) to "OFF" position & turn the handle
bar towards left or right & push the key
downwards & turn towards "Lock" position.
After locking take out the key.
1
1
(2) i3s indicator
2
