î Tighten the nut after adjustment.
WARNING
!!
An improperly adjust headlamp may blind
oncoming rider/driver or it may fail to light
the road for a safe distance.
SUSPENSION
Inspection
î Check the front forks by locking the front
brake and pumping the front fork up and
down vigorously. The suspension action
should be smooth and there should be no oil
leakage.
î Check the rear shock absorber by pushing
hard downwards on rear grip while the
motorcycle is not parked on stand. The
suspension action should be smooth and
their should be no oil leakage.
Rear Shock Absorber Adjustment
Rear shock absorber adjustment can be made
according to the load/road conditions.
î In direction A Stiffer
î In direction B Softer
NOTE
Always adjust both the rear shock absorber to
the same position. Use the pin spanner (1)
available in the tool kit.
(1) Headlamp adjusting bolts
Front Rear
1
B
A
(1) Pin spanner
1
