FUEL VALVE
The three way fuel valve is on the left side of
the carburetor.
“OFF” Position
At “OFF” position (1) , fuel cannot flow from
the tank to the carburetor. Turn the valve
“OFF” whenever the motorcycle is not in use.
(1) “OFF” Position
1
“ON” Position
17
(2) Side stand switch
A side stand switch (2) is provided in the side
stand, when the vehicle is parked on side stand
(Ignition Switch “ON”), the switch enables the
side stand indicator lamp to glow on the
speedometer panel.
(2) “ON” Position
2
2
(1) Side stand indicator
1
