(1 )4 Master cylinder
(15) i3s switch
(16) Rear view mirror
(17) Front brake lever
(18) Turn signal indicator
(19) Throttle grip
(20) tarter switch Electric s
(21) Ignition switch with steering lock
(22) High beam indicator
(23) Fuel tank cap
(24) Side stand indicator
(25) Leg guard
( 6) Neutral 2 indicator
(1) Turn signal switch
(2) Horn switch
(3) Headlamp dimmer switch
(4) Clutch lever
(5) Pass lamp switch
(6) Bystarter lever
(7) Tripmeter knob
(8) Odometer
(9) Speedometer
(10) Tripmeter
(11) Fuel gauge
(12) Tachometer
(13) i3s indicator
*Accessories and features shown may not be part of standard fitment.
MOTORCYCLE VIEWS
TOP VIEW
12
9
1
7
2
5
17
19
3
4
6
10
22
20
23
25
26
8
11
16
21
18
24
13
14 15
