HERO MAESTRO EDGE 2021 - Part Functions; Instruments and Indicators

14
PART FUNCTIONS
INSTRUMENTS AND INDICATORS
The indicators are in the speedometer panel
above the headlamp. The functions are as
below.
1
2
9
345
11
8
10 12
7
Sl. No.
Description
Function
6
High beam indicator Light glows when headlamp is in high beam.
7
1
2
Side stand indicator
3
4
5
Indicates how many kilometer are left before the
next service is due. It appears for few seconds when the
ignition switch is turned “ON” ( ) (page 19).
Next service distance
Indicator glows for 2 seconds and turns “OFF”
indicating that i3s system is functional.
i3s indicator
Turn signal indicators
Flashes when turn signal switch is operated.
Low fuel indicator
Light glows when the fuel quantity is low (page 19).
Light glows when the vehicle is parked on the side stand.
To adjust clock, date & tripmeter.
When long pressed resets tripmeter to zero.
Set button
8
Mode button
To change the mode (tripmeter-1 & 2 & navigation
mode), clock and date adjust.
13
6
