(1) Air cleaner cover screws
(2) Air cleaner cover
1
2
(5) Pre foam element
(6) Viscous air cleaner element
5
Viscous air cleaner element inspection
•
. R Replace the element, if found choked efer
maintenance schedule (page 61).
•
Inspect the viscous air cleaner element (6)
for any dust or dirt accumulation.
6
AIR CLEANER ELEMENT
Refer to the safety precautions . (page 60)
The air cleaner element is of pre foam and
viscous type replaced , it should be at regular
intervals . (pages 61) Early replacement may
be required when riding in unusually wet or
dusty areas.
Removal
• (page 41)Remove the body cover .
• Remove the air cleaner cover (1) by
removing the screws (2)
•
Remove the air cleaner element holder
component (3) from air cleaner sub
assembly case (4).
•
Separate the pre foam element (5) from
the air cleaner assembly.
4
(3) Air cleaner element holder component
(4) Air cleaner sub assembly case
3
