HANDLEBAR SWITCHES CONTROL
1. Dimmer switch/Passing switch
Press the switch upwards for high beam
Press the switch to pass lamp position to
operate the pass lamp.
Left handlebar controls
2. Turn signal switch ( )
Shift the turn signal switch sideways for
right/left indications and leave it to come
“ ” and downwards for low beam “ ”.
back to its normal position on its own.
IMPORTANT: To switch “OFF” the turn
signal after completing the turn, gently push
inside as directed on the switch.
3. Horn switch ( )
Press the horn switch to operate the horn.
(1) Electric starter switch (2) i3s switch
(1) Dimmer switch/Passing switch
(2) Turn signal switch
(3) Horn switch
1
3
2
1
2
The starter switch (1) is next to the throttle
grip.
Right handlebar controls
1. Starter switch ( )
When the starter switch is pressed, the starter
motor cranks the engine. See (page 50) for
the starting procedure.
NOTE
During electric & throttle start, the engine will
turn off automatically, even though i3s switch
is “ON” or “OFF”:
•
Engine reaches 900±100 r/min
•
The starter relay is engaged for more than 5
seconds.
2. i3s switch
There is an i3s switch (2) provided to enable
the rider for turning i3s mode “ON” or “OFF”
based on the traffic conditions.
•
Turn the ignition key to “ON” ( ) position.
•
Keep the i3s switch (1) to “OFF” position.
Starting & Warm up the engine:
FEATURES
(a) i3s (Idle stop start system)
