HERO MAESTRO EDGE 2021 - Floor Side Cover

Removal
•
Remove the three screws (1) from right
floor side cover (2).
Right floor side cover
(e) Floor side cover
•
Open the pillion footrest (page 40).
46
1
(1) Screws (2) Right floor side cover
2
•
To dislodge the tabs (3), slide the floor side
covers to the rear side.
(3) Tabs
3
• Remove the right floor side cover.
Installation
Left floor side cover
Installation is in the reverse order of removal.
Removal
• Open the pillion footrest (page 40).
• Remove the three screws (1) from left floor
side cover (2).
1
(1) Screws (2) Left floor side cover
2
(3) Tabs
3
