20
NOTE
NOTE
After getting the vehicle serviced, make sure that
the service reminder indicator has been reset.
The service reminder indicator can be reset at
an Authorised Distributor/Dealer.
KEYS
This vehicle has two keys and a key number
plate.
You will need the key number if you ever have
to replace a key. Store the plate in a safe
place.
MAJOR COMPONENTS
(Information you need to operate this
vehicle)
BRAKES (INTEGRATED BRAKING)
Brakes are items of personal safety and should
always be maintained with proper adjustments.
When one applies the left lever, front & rear
brakes activate jointly.
(1) Keys (2) Key number plate
1 2
(1) Front brake lever
1
3
Meter console also displays the next service
distance (2). It indicates how many kilometers
are left before the next service is due. It
appears for few seconds when the ignition
switch is turned “ON” ( ).
(2) Integrated brake lever
(3) Free play:10-20 mm
2
3
