HERO MAESTRO EDGE 2021 - (16) Body Cover; Front Center Cover

44
(16) Body cover
16
(1) Screws
1
•
Remove the two screws (2) near the front
fender.
Removal
(c) Front center cover
Installation is in the reverse order of removal.
•
Remove the two screws (1) on the inner
cover side.
Installation
(2) Screws
2
While removing the front centre cover, make
sure to open the cover cautiously to avoid
position lamp wire breakage.
NOTE
•
Disconnect the position lamp connector
(3) and release the front center cover lugs
(4) from the mounting clips. Remove the
front center cover by pulling it axially
downwards towards front.
(3) Position lamp connector (4) Lugs
4
3
