45
(d) Front cover
Removal
Installation
Installation is in the reverse order of removal.
•
Remove the front center cover (page 44).
•
Remove the six screws (1) from the inner
cover side.
•
Remove the four bolts (2) from the front
cover.
(1) Screws
1
(3) Screws(2) Bolts
3
2
•
Remove the front cover and disconnect the
front turn signal lamp connectors (5).
(4) Screws
4
(5) Front turn signal lamp connectors
4
5 5
•
s Remove the top and bottom screw (3).
•
4 from side Remove the screws ( ) the floor
covers.
Installation
Installation is in the reverse order of removal.
