The indicators are in the speedometer panel
above the headlamp. The functions are as
below.
Instruments and Indicators
13
7
4
Function Description
Sl. No.
(1)
(2)
(3)
(4)
(5)
(6)
Turn signal indicators Indicates the turn signal lamp operation to the rider.
lamp (MIL)
Programmed-FI
malfunction indicator
When the ignition switch is turned “ON” the
programmed FI malfunction indicator lamp (MIL)
glows continuously and then should go “OFF” once
the engine is started. It indicates that programmed FI
system is OK. If it glows continuously there is an
abnormality in the programmed FI system, it is
recommended to reduce the speed and drive to the
Authorised Hero MotoCorp workshop for check-up.
3
6
8
2
1
5
9
101112
Neutral indicator position. Light glows when vehicle is in neutral
High beam indicator
“ ”Light glows when headlamp is in Hi beam.
Indicates riding speed.
Speedometer
Indicates approximate fuel quantity in the form of
digital segments. The fuel gauge segments will display
its maximum scale on the fuel gauge LCD panel once
when the ignition switch it turned "ON".
Fuel gauge
To Next Page
