37
• Adjust the clutch cable free play, if required
(page 40).
• Reinstall the dowel pins, new gasket,
•
Reinstall the oil filter screen with the sharp
edged side facing inwards.
crankcase cover, rider footrest assembly
with side stand, exhaust muffler, kick starter
pedal and clutch cable.
• Install the side stand switch screw.
• Fill the crankcase with clean engine oil as
per specification.
Ensure to replace gasket with new one once
removed.
NOTE
• Remove the oil filter screen (9) and wash it
in clean non flammable or high flash point
solvent (kerosene).
• Remove the gasket (7) and dowel pins (8).
(7) Gasket (8) Dowel pins
(9) Oil filter screen
7
8
9
• (page 21).Remove the seat
• 1Remove the air cleaner cover screws ( )
and the cover ( ).2
AIR CLEANER
Air cleaner element inspection
The air cleaner is viscous paper pleated type
filter which has enhances filtering efficiency.
The air cleaner replacedshould be at regular
intervals When riding in dusty (page 30).
areas, more frequent may be replacement
necessary.
(1) Air cleaner cover screws (2) Cover
2
1
•
Remove the air cleaner element (3).
