Battery installation
•
Reinstall in the reverse order of removal. Be
sure to connect the positive (+) terminal ve
first, then the negative (-) terminal.ve
FUSE REPLACEMENT
Spare fuse (4) : 15A, 10A
•
Check all fasteners are secured properly.
In circuit fuse (3) : 15A, 10A, 10A & 10A
Fuse box : air (1) Location: Mounted on the
cleaner assembly 2 ( ).
Fuse ype: t Blade fuse
• (8) Pullout the battery from the battery box.
1
(1) Fuse box (2) Air cleaner assembly
(3) In circuit fuse: 15A, 10A, 10A & 10A
(4) Spare fuse: 15A & 10A
2
4 3
WARNING
!!
•
Battery gives off explosive gases. Keep
sparks, flames & cigarettes away.
•
Never use a fuse with a different rating from that
specified. It may lead to serious damage to the
electrical system or a fire due to short circuit.
CAUTION
!!
•
Turn the ignition switch "OFF" before
checking or replacing the fuse to prevent
accidental short-circuiting.
•
Do not attempt to start or ride the vehicle
without a charged battery, it can cause
fusing of the bulbs and permanent damage
to certain electrical components.
should be adjusted before performing stop
lamp switch adjustment. The procedure for
adjusting stop lamp switch is as follows:
•
Turn the adjusting nut (2) to position stop
lamp switch at a point where the stop lamp
will glow just before the brake pedal is
depressed to the limit of its free play. Turn
the adjusting nut in direction (A) to advance
switch timing or in direction (B) to retard
switch timing.
•
Turn the ignition switch to the “ON” ( )
position.
The stop lamp switch (1) must be adjusted so
that stop lamp will glow when rear brake is
applied. Rear brake free play (page 47)
STOP LAMP SWITCH
