(1) Speedometer
(2) Neutral indicator
(4) Horn switch
(5) Turn signal switch
(3) Dimmer switch
(6) Clutch lever
(7) Passing switch
(10) Turn signal indicators
(9) High beam indicator
(8) Rear view mirror
(11) Fuel gauge
(12) Tripmeter
(14) Side stand indicator
(13) Programmed FI malfunction indicator
lamp (MIL)
(16) Odometer
(18) Front brake lever
(19) Throttle grip
(21) Service reminder indicator
(22) Reset button
(23) Ignition switch with steering lock
(24) Fuel tank cap
(17) Master cylinder (Optional)
(15) i3s switch/indicator
(20) Electric starter switch
*Accessories and features shown may not be part of standard fitment.
16
8
TOP VIEW
VEHICLE VIEWS
6
7
18
23
4
5
3
2
13
14
15
17
19
20
21
22
24
12
1
11109
