14
Neutral indicator
9
10
11
position. Light glows when vehicle is in neutral
i3s indicator
Indicator glows for 2 seconds and turns “OFF” indicating
that i3s system is functional.
lamp (MIL)
Programmed-FI
malfunction indicator
When the ignition switch is turned “ON” the programmed FI
malfunction indicator lamp (MIL) glows continuously and
then should go “OFF” once the engine is started. It indicates
that programmed FI system is OK. If it glows continuously
there is an abnormality in the programmed FI system, it is
recommended to reduce the speed and drive to the
Authorised Hero MotoCorp workshop for check-up.
Sl. No.
Description
Function
Low fuel indicator
Light glows when the fuel quantity is low (page 17).
12
It indicates the current mileage of the vehicle (in km/litre).
The indication will change after every 3±1 seconds depending
upon the driving condition (page 16).
Real time mileage
indicator (RTMI)
13
Bluetooth
On pairing (page 18), meter console display bluetooth
symbol in bluetooth connected.
14
Phone battery status
If your smartphone is paired with the meter console of your
vehicle via bluetooth (page 18), then it will display battery
status of smartphone on the meter console (page 21).
15
Odometer
16
Shows accumulated distance travelled (page 15).
Mode button Switches display between odometer and tripmeter-A & B.
17
Speedometer Indicates driving speed.
19
Tripmeter
Shows the distance travelled during a trip after setting to
zero (page 15).
18
Scroll display
Displays a scrolling “HELLO HERO MOTOCORP” message for few
seconds when the ignition key is turned “ON” (page 16).
20
