SEAT LOCK
Location : On the rear left side of the seat,
below the rear cowl.
the lock clicks.
Operation : To unlock the seat, insert the
ignition key (1) and turn in clockwise
direction. To install, engage the hook on the
underside of the seat with the frame and push
on the top rear side of the seat until
(1) Ignition key
1
HELMET HOLDER
The helmet holder is located below the
seat. Remove the seat. Hang the helmet on
the helmet holder (1) by using wire helmet
set (2) (optional). Install the seat (3) and
lock it securely.
(1) Helmet holder hook
(2) Wire helmet set (optional) (3) Seat
3
1 2
WARNING
!!
•
Riding with a helmet attached to the holder
can interfere with the rear wheel of
suspension and could cause a crash in which
you can be seriously hurt of killed.
•
Use the helmet holder only while parked. Do
not ride with a helmet secured by the holder.
A USB charger (1) with a cap (2) located on
the left side of the inner panel (3) near meter
console to charge your mobile phone safely
while riding.
USB CHARGER
To connect a mobile phone to the charger,
first open the cap from the USB charger and
then plug in the charger cable to it. Hero
MotoCorp will not be responsible for damages
caused due to use of non-standard USB cable.
Use of non-standard USB cable may cause
damage to the mobile phones.
28
