(1) Phone battery status
80-100%
60-79%
40-59%
20-39%
1-19% (Blink)
Left handlebar controls
1. Clutch switch
HANDLEBAR SWITCHES CONTROL
There is a clutch switch (1) provided for the
safety of the rider. The vehicle cannot be
started by electric starter switch until the clutch
lever is operated when the vehicle is engaged
in gear.
1
4
3. Dimmer switch
Select “ ” for high beam and “ ” for
low beam.
4. Turn signal lamp switch ( )
Shift the turn signal lamp switch (4) sideways
for right/left indications and leave it to come
back to its normal position on its own.
IMPORTANT: To switch “OFF” the turn
signal after completing the turn, gently push
inside.
5. Horn switch ( )
Press the horn switch (5) to operate the horn.
(3) Dimmer switch
(4) Turn signal lamp switch
(5) Horn switch
(1) Clutch switch (2) Passing switch
1
Press passing lamp switch (2) to operate the
passing lamp.
2. Passing switch
Gives an indication for passing ahead.
3
5
22
2
