56
• Rider + Pillion: 5th position
Recommend adjustment
• Check the rear shock absorber by pushing
hard downwards on rear grip while the
vehicle is not parked on stand. The
suspension action should be smooth and
there should be no oil leakage.
Rear shock absorber adjustment
Rear shock absorber adjustment can be made
in any position from 1st to 5th according to the
load/road conditions or owner’s requirement.
• Solo rider : 2nd position
B
A
(1) Rear shock absorber (2) Pin spanner
(A) Stiffer (B) Softer
2
1
NOTE
Always adjust both the rear shock absorbers to
the same position. To adjust the rear shock
absorber (1), use the rear shock absorber
adjustment tool (Pin spanner) (2) available in
the tool kit.
WHEEL
(a) Front wheel (Disc variant)
Removal
•
Remove the front axle nut (1).
•
Support the vehicle securely on the main
stand and raise the front wheel off the
ground.
•
Remove the axle (2) and the wheel.
•
Remove the side collar (3) from the wheel.
• In direction B: Softer
• In direction A: Stiffer
CAUTION
!!
Do not operate front brake lever when the
wheel is removed.
(1) Axle nut (2) Axle (3) Side collar
3
•
Position the front wheel between the fork
legs by aligning the slot with lug on the fork
leg and the disc between the brake pads to
avoid damage to the pads. Insert the axle
from the right side through the fork legs and
wheel hub.
•
Install the side collars (1) to both sides of
the wheel hub
Installation
1
2
