Ensure to replace gasket with new one once
removed.
NOTE
• Remove the oil filter screen (10) and wash
it in clean non flammable or high flash point
solvent (kerosene).
• Remove the gasket (8) and dowel pins (9).
(8) Gasket (9) Dowel pins
(10) Oil filter screen
• (page 28).Remove the seat
AIR CLEANER
• 1Remove the air cleaner cover screws ( )
and the cover ( ).2
Air cleaner element inspection
The air cleaner is viscous paper pleated type
filter which has enhances filtering efficiency.
The air cleaner replacedshould be at regular
intervals When riding in dusty (page 37).
areas, more frequent may be replacement
necessary.
(1) Air cleaner cover screws (2) Cover
2
1
9
8
10
•
Mount the side stand switch wire clip on to
the footrest assembly.
•
Reinstall the oil filter screen with the sharp
edged side facing inwards.
• Install the side stand switch screw.
• Adjust the clutch cable free play, if required
(page 47).
crankcase cover, rider footrest assembly
with side stand, exhaust muffler, kick starter
pedal and clutch cable.
• Reinstall the dowel pins, new gasket,
• Fill the crankcase with clean engine oil as
per specification.
