The real time mileage indicator (RTMI) (1)
shows the current mileage of the vehicle in
km/litre and is refreshed after every 3±1
seconds.
(d) Real time mileage indicator (RTMI)
16
The fuel consumption shall be displayed when
the speed of the vehicle is more than 5±2
km/hr. If the speed is less than 5±2 km/hr
"--.-" shall be displayed.
When the ignition switch is turned “ON” ( )
position, the real time mileage indicator will
temporarily show the digit "99.9" which
indicates that all the digital LCD segments are
working. The display range is from (0 to 120
km/litre).
The RTMI shows a minimum value of
0.0km/litre and maximum value of
120 km/litre. During coasting with throttle
fully closed, the fuel consumption is very
minimal and hence the display can go up to
120
km/l
AV
km/h
km
odo
TRIP
AB
MODE
(1) Real Time Mileage Indicator (RTMI)
(2) Mode button
2 1
The service reminder indicator (1) is to
indicate user to bring the vehicle to an
(f) Service reminder indicator
Authorised Hero MoroCorp workshop for
service. The indicator shall start blinking when
the vehicle covers kilometers as specified in
the maintenance schedule. The indicator will
keep on blinking throughout the kilometer
interval for a particular service and will stay
“ON” thereafter. The service reminder
indicator can be reset at an Authorised Hero
MoroCorp workshop.
The scroll (1) display a message “HELLO HERO
MOTOCORP” after for few seconds whenever the
ignition is turned “ON”.
(e) Scroll message
km/l
AV
km/h
km
odo
HERO MOTOCORP
MODE
1
(1) Scroll message
NOTE
NOTE
If the user name “VIJAY” is assigned in hero
ride guide application (page 19) then user
name will come as “HELLO VIJAY“, instead of
“HELLO HERO MOTOCORP“
