Support the vehicle securely on the main
stand and raise the rear wheel off the
ground.
(c) Rear wheel
Removal
(10) Lug (11) Slot
10
11
(8) Axle nut (9) Axle (10) Collar
8
9
10
•
Reverse the removal procedure
Installation
2.2 kgf-m
Brake stopper arm nut torque:
•
After installing the wheel, apply the brake
several times and check for free wheel
rotation when released.
Axle nut torque: 5.4 kgf-m.
•
Adjust the rear brake free play (page 54)
and drive chain slackness (page 49).
5 2
7
(1) Rear brake adjusting nut (2) Brake rod
(3) Brake arm (4) Brake stopper arm
(5) Brake panel (6) Split pin (7) Lock nut
6
brake arm (3) by pushing down the brake
pedal. Disconnect the brake stopper arm
(4) from the brake panel (5) by removing
split pin (6) and lock nut (7).
•
Remove the rear axle nut (8).
•
Remove the wheel.
•
Pull out the axle (9) and collar (10).
CAUTION
!!
Always replace used split pins with new ones.
•
Remove the rear brake adjusting nut (1)
and disconnect the brake rod (2) from the
3
1 4
