HERO PASSION XTEC - Page 7

4
(1) Exhaust muffler
(2) Kickstarter pedal
(3) Rider footrest
(5) Oil level dipstick
(4) Rear brake pedal
(7) CCB valve (inside)
(6) Starter motor
(8) Caliper assembly
#
(9) Front disc
#
(10) Front suspension
(12) Front visor
(1 ) ear 5 R shock absorber
( 1) Headlamp1
(1 )3 Throttle body/ECU (inside)
(14) Licence plate lamp
RIGHT SIDE VIEW
10
11
12
2
5
8
6
1
9
14
3 4
7
13
15
*Accessories and features shown may not be part of standard fitment.
#
Disc Variant
