(2) Brake pads (3) Caliper (4) Disc
3
NOTE
• Always contact your Authorised Hero
MoroCorp workshop for refilling of master
cylinder when necessary . Do not mix DoT 3
and DoT 4 brake fluid.
• Clean the dirt and mud accumulation
between the brake pads (2), caliper (3) and
the disc (4) by using a water jet.
(b) Rear brake fluid (Disc variant)
Brake fluid recommended :
Location : Near the right side pillion footrest.
DoT-4/DoT-3.
Refer to the safety precautions on (page 27).
Reservoir (1)
Fluid level - Ensure that the brake fluid level
does not fall below "MIN" mark (2) on the
reservoir parallel to the ground. The level
decreases gradually due to piston movement
to compensate pad wear. If the level decreases
(1) Reservoir (2) "MIN" mark
dirty roads. Inspect the pads at each regular
maintenance interval.
Brake pad wear depends upon the severity of
usage, the type of riding & road conditions.
Generally, the pads will wear faster on wet &
• Always replace both the pads as a set.
• Replace the pads if worn out to the bottom
of the groove.
(c) Brake pad wear (Disc variant)
Inspection
• groovesCheck the wear indicator (1) on
each pad.
• Authorised Visit your Hero MoroCorp
workshop for the brake pad replacement.
• Check the brake pads for wear by
examining the wear limit groove on each s
pad.
abruptly, check for the leakages in the brake
system and consult your Authorised Hero
MoroCorp workshop.
MIN
MAX
2
4
1
2
