9. OXYGEN SOURCE
OXYMO works gently while connected to a medical oxygen source with outlet
pressure 1,5 ± 0,15 bar and capacity higher than 25 L/min.
The device allows for three types of oxygen supply:
1. Compressed oxygen cylinder.
2. Low pressure oxygen pipeline (hospital).
3. Liquid oxygen tank (LOX).
9.1. HIGH PRESSURE CYLINDER
To connect OXYMO to a high pressure oxygen cylinder, pressure should be
reduced to 1.5 bar. To achieve this it can be used in conjunction the pressure
cylinder regulator P-300 and the OXYMO P-15 MICRO regulator (See
Chapter
4).
Once both regulators are connected to an oxygen cylinder, connect directly
the spiral hose to the outlet of the OXYMO P-15 MICRO regulator and to the
oxygen inlet connector of OXYMO.
I NOTE .
As a cylinder pressure regulator, it can be used HERSILL P-300 regulator or
a regulator by another manufacturer, if with a standard DISS valve, a
pressure ranging 2.8 -7 bar and flows higher than 100 L/min.
