CP : control panel, FC : frequency converter, SB : supply board, CB : cooling board, CC : control cable, LL : lid locking, BC : braking chopper,
BR : brake resistor, MR : mains reset
11/49
4. Error messages
4.1. Brief description
• Error messages in:
UNIVERSAL 32
UNIVERSAL 32 R
Error designation No. Brief description Page
TACHO-ERROR 01 Speedometer pulses break down during rotation 13
TACHO-ERROR 02 No speedometer pulses after start command 13
IMBALANCE Imbalance on motor axle 14
CONTROL-ERROR 04 LL error, lid opened without recognizing that
motor had stopped
14
N > MAX 05 Excessive speed error, 250 RPM above n-max of
rotor
14
ROTORCODE 10 Invalid rotor code 16
MAINS INTERRUPT Mains interruption 16
VERSION-ERROR 12 Error in initialization 16
N < MIN 13 Speed error, slippage is too great 17
CONTROL-ERROR 21 CP - error: speed 17
CONTROL-ERROR 22 CP - error: I²C bus 16
CONTROL-ERROR 23 CP - error: display memory 16
CONTROL-ERROR 24 CP - error: clock timeout 16
CONTROL-ERROR 25 CP - error: EEPROM 16
CONTROL-ERROR 26 CP - error: driver defective 16
N > ROTOR-MAX --- CP - error: nominal speed is higher
than permitted rotor speed
or nominal RCF is higher
than permitted rotor RCF
16
SER I/O-ERROR 30 No connection between CP and serial interface 17
SER I/O-ERROR 31 No connection between FC and serial interface 17
SER I/O-ERROR 33 Subassembly data incorrectly transmitted 17
SER I/O-ERROR 34 Data incorrectly transmitted between CP and FC 17
SER I/O-ERROR 36 No acknowledgement (NAK) from FC to CP 17
No cooling
(No error displayed)
Overtemperature at condenser 18
°C / *-ERROR 52 Overtemperature in centrifuge chamber 18
°C / *-ERROR 53 Temperature sensor in centrifuge chamber is
defective
18
