7. Functional check
7.1. Functional check at factory
Following assessories are required to perform the functional check:
− Testing rotor
− Two reaction receptacles filled with water
Table 7 lists measured values, and, ranges of measured values, which have been laid
down for these assessories.
In the final check, the functional efficiency of each centrifuge is verified, with the meas-
ured values and ranges of measured values being taken into account.
Table 7
UNIVERSAL Measurements carried out on the centrifuges at the
factory 32 32 R
testing rotor 1628
- with bucket 1621
- load: two tubes 15 ml
- tubes filled with 10 ml glycerin
Measuring instruments used in final check
Temperature measuring instrument THERM 2250-1 X
Moving-iron current measuring instrument X
Rated speed n
max
RPM 4500
Slippage at n
max
RPM 4500-5000
Test rotor for current consumption 1615
Rated current up to n
max
A 1,8 2,7
Total current with cooling
A --- 4,1
Starting time Stage 9 up to 4500 rpm sec 30 – 38
Rundown time Stage 9 from 4500 rpm sec 30 – 38
Starting time Stage 4 up to RPM 1500 sec 25 – 33
Rundown time Stage 4 from RPM 1500 sec 30 – 37
Imbalance Run through at g
≤ 4 ≤ 6
Switch off at g
≥ 8 ≥ 10
