Web-Based Access Control Solution
ACW2-XN
4 System Specifications
Hardware Capabilities
Feature
Specification
Max People 1000
Max Cards 3 Cards per Person
Max Logs 100 000 events
# of Doors
2 Doors or 1 APB Door
(*Expandable to 8 doors, or 8 APB Doors)
Note:
• Additional ACW2-XN and/or AW2 modules are required.
5 Electrical Specifications
Power Supply (A-X1)
AC Mains Input DC Output
100-230 VAC (50/60Hz), 1.3A 12V, 5A
Battery Charging Circuit
Conditions Current Power
Supply at 12V DC, battery flat, max charge current 500 mA 6 W
Optional Battery (Strongly recommended)
Not included with the ACW2-XN, this battery must be sourced separately.
Note:
• Only connect the battery after all system wiring is complete and tested on the built-in power
supply
Battery Specification
Type Lead Gel
Voltage 12V
Capacity 7 Ah
Physical Dimensions 65 mm x 101 mm x 151 mm – or smaller
Battery Protection Fuse Specification
Length 20 mm
Type Slow-blow
Rating 6.3 A
