HDP8500 Industrial Card Printer/Encoder User Guide L001617 rev 1.1
Selecting the Clean Printer tab
The button for the Clean Printer tab is described below.
Clean Button: Launches cleaning routine. Follow the instruction on the page for setting up
the Printer.
Help button: Launches help that is specific to this tab.
Use the CR80 size cleaning card. Part Number: 085974
Using the Printer Driver option
Set up the Printer and click the Clean Printer tab.
a. Remove the Card, Film and Laminate Cartridges and close the covers.
b. Remove the paper back from both sides of the Cleaning Card. (Note: DO
NOT remove the left liner if a Magnetic Encoding Module is installed in your
printer.)
c. Insert the Cleaning Card into the Card Hopper 2.
d. Click on the Clean button.
e. Guide the Cleaning Card into the Printer as needed.
