HDP8500 Industrial Card Printer/Encoder User Guide L001617 rev 1.1
(Note #2: This option is not available if using a YMCKH Ribbon.)
Using the Print Both Sides - Print Back Image on Front of
Card option
This option becomes active when Print Both Sides is checked. The Default is active and
unchecked.
Select this option:
If you need to print the first page of a two-page document on the
backside of the card.
OR
If you need to print the resin black on the chip-side of the Smartcard.
The second page of the document will be printed on the front side of the
card.
Using the Dual Sided - Print Back Side Only option
Use this option to print only onto the backside of cards. (Note: The Print Back Side Only
checkbox default is active and unchecked.)
Select this option to print only onto the backside of preprinted cards that must
have their Magnetic Stripe or smart card chip encoded. (Note: Load the
