PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
V-6
NO
YES
Look up the frequency
drive parameters
setting listed on the
electrical schematics.
Are all parameters set
correctly?
Restore drive
parameters setting.
Remove the film
carriage motor wires
off the frequency drive;
connect them to the
turntable frequency
drive. Run the
turntable manually
using the jog button on
the operator panel. Is
the film carriage motor
running?
Check film carriage
motor for
mechanical
restrictions. Replace
if necessary.
Replace the film
carriage frequency
drive.
Continued to page V-7
Continued from page V-5
Locate the film
carriage motor, and
use a voltmeter to
check continuity of all
motor wires. Is the
frequency drive
connected properly to
the motor?
Tighten or replace
wiring as necessary.
