User Manual of DS-7200/7300/8100 Series DVR
115
6.2.3 Reverse Playback of Multi-channel
Purpose:
You can play back record files of multi-channel reversely.
Steps:
1. Enter the Playback interface.
Menu>Playback
2. Check checkbox to select the channel(s) and double-click to select a date on the calendar.
If more than one channel is optional, the synchronous playback will be activated.
Figure 6. 21 4-ch Synchronous Playback Interface
3. Click the icon on the playback control toolbar, and the record files will be played back reversely.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7200 and is the answer not in the manual?

HIKVISION DS-7200 Specifications

General IconGeneral
Hard Disk1 SATA interface
Video Input4/8/16 channels
Video Output1 HDMI, 1 VGA
Audio Output1 channel, RCA
HDD CapacityUp to 6TB
Network ProtocolsTCP/IP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP
Network Interface1 RJ45 10M/100M adaptive Ethernet interface
USB Interface2 USB 2.0
Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
Video CompressionH.264+
Encoding Resolution1080p/720p/4CIF/CIF
