User Manual of DS-7200/7300/8100 Series DVR
35
2.2 Adding and Connecting the IP Cameras
This Chapter is available for the HDVR models only.
2.2.1 Adding the IP Cameras
Purpose:
The HDVR series can be connected with the network cameras and record the video from them. Before you
can get a live view or record of the video, you should add the network cameras to the connection list of the
device.
Before you start:
Ensure the network connection is valid and correct. For detailed checking and configuring of the network,
please see Chapter 9.1 Configuring General Settings, Chapter 9.3 Checking Network Traffic and Chapter 9.4
Network Detection.
Steps:
1. Enter the Camera Management interface.
Menu > Camera> Camera
Figure 2. 11 Main Menu
2. Add the online cameras:
1) On the IP Camera interface, the online cameras in the same network segment with the device can
be detected and displayed on the list. You can click the button Refresh to refresh the information
of the online cameras.
For the 4-ch HDVR, 1 IP camera can be added, and for the 8-ch and 16-ch HDVR, 2 IP cameras
can be added.
