User Manual of DS-7200/7300/8100 Series DVR
62
4.2 Configuring PTZ Settings (B)
This section is applied to the Smart/Coaxitron HDVR and Smart DVR/HDVR series.
Purpose:
Follow the procedure to set the parameters for PTZ. The configuring of the PTZ parameters should be done
before you control the PTZ camera.
Before you start:
Make sure that the PTZ camera and the device are connected properly via RS-485 interface.
Steps:
1. Enter the PTZ Settings interface.
Menu > Camera > PTZ
Figure 4. 15 PTZ Settings
2. Select the camera for PTZ setting from the drop-down list.
3. Click the RS-485 Settings button and then configure the RS-485 parameters of the device.
4. Enter the parameters of the PTZ camera.

HIKVISION DS-7200 Specifications

General

Hard Disk	1 SATA interface
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel, RCA
HDD Capacity	Up to 6TB
Network Protocols	TCP/IP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP
Network Interface	1 RJ45 10M/100M adaptive Ethernet interface
USB Interface	2 USB 2.0
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Video Compression	H.264+
Encoding Resolution	1080p/720p/4CIF/CIF
