User Manual of DS-7200/7300/8100 Series DVR
148
9.1 Configuring General Settings
Purpose:
Network settings must be properly configured before you operate device over network.
Steps (for DS-7200, DS-7300 and DS-8104/8108):
1. Enter the Network Settings interface.
Menu > Configuration > Network
2. Select the General tab.
Figure 9. 1 General Network Settings of DS-7204/7208/7216
Figure 9. 2 General Network Settings of DS-7224/7232 and DS-7300
The DS-7204/7208/7216 models provide one 10M/100Mbps self-adaptive network interface, the
DS-7224/7232, DS-7300 and DS-8104/8108 models provide one10M/100M/1000Mbps self-adaptive
network interface.
3. In the General Settings interface:
You can configure the following settings: NIC Type, IPv4 Address, IPv4 Gateway, MTU and DNS
Server.

HIKVISION DS-7200 Specifications

General

Hard Disk	1 SATA interface
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel, RCA
HDD Capacity	Up to 6TB
Network Protocols	TCP/IP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP
Network Interface	1 RJ45 10M/100M adaptive Ethernet interface
USB Interface	2 USB 2.0
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Video Compression	H.264+
Encoding Resolution	1080p/720p/4CIF/CIF
