User Manual of DS-7200/7300/8100 Series DVR
146
8.8 Triggering or Clearing Alarm Output
Manually
This section is available for DS-7224/7232, DS-7300, DS-8100 and HDVR models only.
Purpose:
Sensor alarm can be triggered or cleared manually. If Manually Clear is selected in the dropdown list of
dwell time of an alarm output, the alarm can be cleared only by clicking Clear button in the following
interface.
Steps:
Select the alarm output you want to trigger or clear and make related operations.
Menu> Manual> Alarm
Click Trigger / Clear button if you want to trigger or clear an alarm output.
Click Trigger All button if you want to trigger all alarm outputs.
Click Clear All button if you want to clear all alarm output.
Figure 8. 27 Clear or Trigger Alarm Output Manually
