User Manual of DS-7200/7300/8100 Series DVR
58
Repeat the above steps to add more key points.
You can also delete all the key points by clicking the trash icon
Figure 4. 8 KeyPoints Deletion
Calling Patrols
Purpose:
Calling a patrol makes the PTZ to move according the predefined patrol path.
Call patrol in the PTZ setting interface:
Steps:
1. In the PTZ setting interface.
Menu> Camera> PTZ> More Settings
2. Select the patrol number, and then click to call the patrol.
3. Click to stop it.
Figure 4. 9 Calling Patrol
Call patrol in live view mode:

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7200 and is the answer not in the manual?

HIKVISION DS-7200 Specifications

General IconGeneral
Hard Disk1 SATA interface
Video Input4/8/16 channels
Video Output1 HDMI, 1 VGA
Audio Output1 channel, RCA
HDD CapacityUp to 6TB
Network ProtocolsTCP/IP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP
Network Interface1 RJ45 10M/100M adaptive Ethernet interface
USB Interface2 USB 2.0
Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
Video CompressionH.264+
Encoding Resolution1080p/720p/4CIF/CIF
