User Manual of DS-7200/7300/8100 Series DVR
21
1.3 USB Mouse Operation
A regular 3-button (Left/Right/Scroll-wheel) USB mouse can also be used with this device. To use a USB
mouse:
1. Plug USB mouse into one of the USB interfaces on the front panel of the device.
2. The mouse should automatically be detected. If in a rare case that the mouse is not detected, the possible
reason may be that the two devices are not compatible, please refer to the recommended device list from
your provider.
The operation of the mouse:
Table 1.5 Description of the Mouse Control
Live view: Select channel and show the quick set menu.
Menu: Select and enter.
Live view: Switch single-screen and multi-screen.
PTZ control: pan, tilt and zoom.
Tamper-proof, privacy mask and motion detection: Select target area.
Digital zoom-in: Drag and select target area.
Live view: Drag channel/time bar.
Live view: Show menu.
Menu: Exit current menu to upper level menu.
Live view: Previous screen.
Right-click Menu: Previous item.
Live view: Next screen.
Right-click Menu: Next item.
1.4 Input Method Description
Figure 1.5 Soft Keyboard
Description of the buttons on the soft keyboard:
Table 1.6 Description of the Soft Keyboard Icons
