User Manual of DS-7200/7300/8100 Series DVR
30
2.1 Using the Wizard for Basic Configuration
The Setup Wizard can walk you through some important settings of the device. By default, the Setup Wizard
starts once the device has loaded.
Operating the Setup Wizard:
1. Select the system resolution from the drop-down menu. The default resolution is 1280×1024/60Hz.
Click Apply to save the resolution settings.
Figure 2. 1 Start Wizard Interface
By default, the system resolution is set to 1280×1024.
2. Check the checkbox to enable Setup Wizard when device starts. Click Next to continue the setup
wizard.
You can also click Cancel to exit the Setup Wizard, or use the Setup Wizard next time by leaving the
“Start wizard when DVR starts?” checkbox checked and exit.
Figure 2. 2 Start Wizard Interface

HIKVISION DS-7200 Specifications

General

Hard Disk	1 SATA interface
Video Input	4/8/16 channels
Video Output	1 HDMI, 1 VGA
Audio Output	1 channel, RCA
HDD Capacity	Up to 6TB
Network Protocols	TCP/IP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP
Network Interface	1 RJ45 10M/100M adaptive Ethernet interface
USB Interface	2 USB 2.0
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Video Compression	H.264+
Encoding Resolution	1080p/720p/4CIF/CIF
