HIKVISION DS-7208HUHI-K2/P User Manual

Digital Video Recorder User Manual
121
Chapter 8 Alarm Settings
8.1 Setting Motion Detection
Step 1 Go to Menu > Camera > Motion.
Figure 8-1 Motion Detection Setup Interface
Step 2 Select a camera you want to set up motion detection.
Step 3 Set detection area and sensitivity.
Check checkbox to enable motion detection. Use the mouse to draw detection area(s)
or click Full Screen to set the detection area to be the full screen and drag the sensitivity
bar to set sensitivity.
Click to set alarm response actions.
Figure 8-2 Set Detection Area and Sensitivity

HIKVISION DS-7208HUHI-K2/P Specifications

General

Bit rate	64 Kbit/s
Audio system	2-way
Product color	Black
Video streaming	Yes
Maximum frame rate	30 fps
Audio formats supported	G.711 μ-law
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Number of simultaneously playbacked channels	8 channels
Audio input	4
BNC input ports	8
USB 2.0 ports quantity	1
Number of users	64 user(s)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	SATA
Maximum HDD capacity	10000 GB
Number of HDDs supported	2
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
DC voltage	48 V
Power consumption (typical)	60 W

Weight and Dimensions

Depth	320 mm
Height	48 mm
Weight	2000 g
