Digital Video Recorder User Manual
145
Step 6 Click Apply to activate the settings.
10.2 Vehicle Detection
Purpose
Vehicle Detection is available for the road traffic monitoring. In Vehicle Detection, the passed
vehicle can be detected and the picture of its license plate can be captured. You can send alarm
signal to notify the surveillance center and upload the captured picture to FTP server.
Step 1 Go to Menu > Camera > VCA.
Step 2 Select the camera to configure the VCA.
You can check the checkbox of Save VCA Picture to save the captured pictures of VCA
detection.
Step 3 Select the VCA detection type to Vehicle Detection.
Step 4 Check the Enable checkbox to enable this function.
Figure 10-4 Set Vehicle Detection
Step 5 Click to configure the trigger channel, arming schedule, linkage action and PTZ linking.
The PTZ linking is only applicable to other list, not to whitelist and blacklist.
Step 6 Click the Rule Settings to enter the rule settings interface. Configure the lane, upload
picture and overlay content settings. Up to 4 lanes are selectable.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7208HUHI-K2/P and is the answer not in the manual?

HIKVISION DS-7208HUHI-K2/P Specifications

General IconGeneral
Bit rate64 Kbit/s
Audio system2-way
Product colorBlack
Video streamingYes
Maximum frame rate30 fps
Audio formats supportedG.711 μ-law
Maximum video resolution3840 x 2160 pixels
Video compression formatsH.264, H.264+, H.265, H.265+
Analog signal format systemNTSC, PAL
Playback resolutions supported3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Number of simultaneously playbacked channels8 channels
Audio input4
BNC input ports8
USB 2.0 ports quantity1
Number of users64 user(s)
Ethernet interface typeFast Ethernet, Gigabit Ethernet
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interfaceSATA
Maximum HDD capacity10000 GB
Number of HDDs supported2
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
DC voltage48 V
Power consumption (typical)60 W
Weight and Dimensions IconWeight and Dimensions
Depth320 mm
Height48 mm
Weight2000 g
