HIKVISION DS-7208HUHI-K2/P User Manual

Digital Video Recorder User Manual
169
12.2.4 Configuring NTP Server
Purpose
A Network Time Protocol (NTP) Server can be configured on your DVR to ensure the accuracy of
system date/time.
Step 1 Go to Menu > Configuration > Network > NTP.
Figure 12-9 NTP Settings Interface
Step 2 Check the Enable NTP checkbox to enable this feature.
Step 3 Configure the following NTP settings:
 Interval: Time interval between the two synchronizing actions with NTP server. The unit is
minute.
 NTP Server: IP address of NTP server.
 NTP Port: Port of NTP server.
Step 4 Click the Apply button to save and exit the interface.
The time synchronization interval can be set from 1 to 10080 minutes, and the default value is 60
minutes. If the DVR is connected to a public network, you should use a NTP server that has a time
synchronization function, such as the server at the National Time Center (IP Address:
210.72.145.44). If the DVR is set in a more customized network, NTP software can be used to
establish a NTP server used for time synchronization.
12.2.5 Configuring NAT
Purpose
Universal Plug and Play (UPnP™) can permit the device seamlessly discover the presence of other
network devices on the network and establish functional network services for data sharing,
communications, etc. You can use the UPnP™ function to enable the fast connection of the device
to the WAN via a router without port mapping.
Before you start
If you want to enable the UPnP™ function of the device, you must enable the UPnP™ function of
the router to which your device is connected. When the network working mode of the device is set
as multi-address, the Default Route of the device should be in the same network segment as that
of the LAN IP address of the router.

HIKVISION DS-7208HUHI-K2/P Specifications

General

Bit rate	64 Kbit/s
Audio system	2-way
Product color	Black
Video streaming	Yes
Maximum frame rate	30 fps
Audio formats supported	G.711 μ-law
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Number of simultaneously playbacked channels	8 channels
Audio input	4
BNC input ports	8
USB 2.0 ports quantity	1
Number of users	64 user(s)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	SATA
Maximum HDD capacity	10000 GB
Number of HDDs supported	2
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
DC voltage	48 V
Power consumption (typical)	60 W

Weight and Dimensions

Depth	320 mm
Height	48 mm
Weight	2000 g
