HIKVISION DS-7208HUHI-K2/P User Manual

Digital Video Recorder User Manual
38
2.4 Basic Configuration in Startup Wizard
Purpose
By default, the Setup Wizard starts once the device has loaded. You can follow it to complete the
basic configuration.
Selecting the language:
Step 1 Select the language from the drop-down list.
Step 2 Click Apply button.
Figure 2-15 Language Configuration
Operating the Setup Wizard:
Step 1 The Start Wizard can walk you through some important settings of the device. If you don’t
want to use the Start Wizard at that moment, click Exit. You can also choose to use the
Start Wizard next time by leaving the “Start wizard when device starts?” checkbox
checked.
Figure 2-16 Start Wizard Interface
Step 2 Click Next button to enter the Change the Password interface.
1) Input the Admin Password.
2) (Optional) Check the checkbox of New Admin Password, input the New Password and
confirm it.

HIKVISION DS-7208HUHI-K2/P Specifications

General

Bit rate	64 Kbit/s
Audio system	2-way
Product color	Black
Video streaming	Yes
Maximum frame rate	30 fps
Audio formats supported	G.711 μ-law
Maximum video resolution	3840 x 2160 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Number of simultaneously playbacked channels	8 channels
Audio input	4
BNC input ports	8
USB 2.0 ports quantity	1
Number of users	64 user(s)
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	SATA
Maximum HDD capacity	10000 GB
Number of HDDs supported	2
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
DC voltage	48 V
Power consumption (typical)	60 W

Weight and Dimensions

Depth	320 mm
Height	48 mm
Weight	2000 g
