Network Video Recorder User Manual
144
7.2 Managing Backup Devices
Management of USB flash drives, USB HDDs and eSATA HDDs
Step 1 Enter the Export interface.
Figure 7-12 Storage Device Management
Step 2 Backup device management.
Click New Folder button if you want to create a new folder in the backup device.
Select a record file or folder in the backup device and click button if you want to delete
it.
Click Erase button if you want to erase the files from a re-writable CD/DVD.
Click Format button to format the backup device.
If the inserted storage device is not recognized:
Click the Refresh button.
Reconnect device.
Check for compatibility from vendor.

Table of Contents

Other manuals for HIKVISION DS-7604NI-K1/4P

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7604NI-K1/4P and is the answer not in the manual?

HIKVISION DS-7604NI-K1/4P Specifications

General IconGeneral
Maximum resolution3840 x 2160 pixels
Video input channels4 channels
Supported resolutions4K(3840 x 2160)/60Hz, 4K(3840 x 2160)/30Hz, 1920 x 1080P/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Product colorBlack
Rack mountingNo
LED indicatorsYes
Audio RCA inputs1
USB 2.0 ports quantity2
Ethernet LAN data rates10, 100 Mbit/s
Copper ethernet cabling technology10BASE-T, 100BASE-TX
Power over Ethernet (PoE) ports quantity4
HDD capacity- GB
HDD interfaceSerial ATA
Maximum storage capacity6 TB
Number of HDDs installed-
Output voltage48 V
Power consumption (max)10 W
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth240 mm
Width315 mm
Height48 mm
Weight1000 g
