HIKVISION DS-7604NI-K1/4P User Manual

Network Video Recorder User Manual
193
11.6 Advanced Search
The DS-7600/7700/8600/9600-I (/P) series NVR supports the advanced search for
fire/ship/temperature/temperature difference detection triggered alarm and the recorded video
files and pictures.
Before you start
To get the smart search result, the corresponding fire/ship temperature/temperature difference
type must be enabled and configured on the connected thermal network camera (Configuration >
Advanced Configuration> Smart Event). Please refer to the user manual of the thermal network
camera for details.
Step 1 Enter the Advanced Search interface.
Menu > VCA Search > Advanced Search
Step 2 Select the camera (s) for the advanced search.
Figure 11-9 Advanced Search
Step 3 Specify the start time and end time for searching the thermal imaging detection results.
Step 4 Select the type to fire detection, ship detection, temperature detection and temperature
difference detection.
Step 5 Click Search to start searching. The search results are displayed in list or in chart.

HIKVISION DS-7604NI-K1/4P Specifications

General

Maximum resolution	3840 x 2160 pixels
Video input channels	4 channels
Supported resolutions	4K(3840 x 2160)/60Hz, 4K(3840 x 2160)/30Hz, 1920 x 1080P/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Product color	Black
Rack mounting	No
LED indicators	Yes
Audio RCA inputs	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Power over Ethernet (PoE) ports quantity	4
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Number of HDDs installed	-
Output voltage	48 V
Power consumption (max)	10 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	240 mm
Width	315 mm
Height	48 mm
Weight	1000 g
