HIKVISION DS-7604NI-K1/4P User Manual

Network Video Recorder User Manual
210
Figure 12-23 Advanced Settings Interface
Step 2 Check the checkbox of the Enable Virtual Host.
Step 3 Click the Save button to save the setting.
Step 4 Enter the IP camera management interface of NVR. The Connect column appears on the
right-most side of the camera list, as shown in the Figure 12-24.
Configuration > Remote Configuration > Camera Management > IP Camera
Figure 12-24 Connect to IP Camera
Step 5 Click the link and the page of IP camera management appears.
12.3 Checking Network Traffic
Purpose:
You can check the network traffic to obtain real-time information of NVR such as linking status,
MTU, sending/receiving rate, etc.
Step 1 Enter the Network Traffic interface.
Menu > Maintenance > Net Detect

HIKVISION DS-7604NI-K1/4P Specifications

General

Maximum resolution	3840 x 2160 pixels
Video input channels	4 channels
Supported resolutions	4K(3840 x 2160)/60Hz, 4K(3840 x 2160)/30Hz, 1920 x 1080P/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Product color	Black
Rack mounting	No
LED indicators	Yes
Audio RCA inputs	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Power over Ethernet (PoE) ports quantity	4
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Number of HDDs installed	-
Output voltage	48 V
Power consumption (max)	10 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	240 mm
Width	315 mm
Height	48 mm
Weight	1000 g
