HIKVISION DS-7604NI-K1/4P User Manual

Network Video Recorder User Manual
196

Two self-adaptive 10M/100M/1000M network interfaces for DS-9600NI-I8, DS-9600NI-I16,
DS-8600NI-K8, DS-7700NI-I4 and DS-7700NI-K4, and the multi-address and network fault
tolerance working modes are configurable.

One self-adaptive 10M/100M/1000M network interface for DS-7600NI-K2/I2(/P),
DS-7700NI-I4/P and DS-7700NI-K4/P.

One self-adaptive 10M/100M network interface for DS-7600NI-K1 (/P).

For the DS-7600NI-I(K)/P and DS-7700NI-I(I)/P series NVR, you need to configure the
internal NIC address, so that IP addresses are assigned to the cameras connected to the PoE
interfaces.
Step 4 After having configured the general settings, click Apply button to save the settings.
Working Mode
Two 10M/100M/1000M NIC cards are provided and it allows the device to work in the
Multi-address and Net-fault Tolerance modes.
Multi-address Mode: The parameters of the two NIC cards can be configured independently.
You can select LAN1 or LAN2 in the NIC type field for parameter settings.
You can select one NIC card as default route. And then the system is connecting with the
extranet the data will be forwarded through the default route.
Net-fault Tolerance Mode: The two NIC cards use the same IP address, and you can select the
Main NIC to LAN1 or LAN2. By this way, in case of one NIC card failure, the device will
automatically enable the other standby NIC card so as to ensure the normal running of the
whole system.

HIKVISION DS-7604NI-K1/4P Specifications

General

Maximum resolution	3840 x 2160 pixels
Video input channels	4 channels
Supported resolutions	4K(3840 x 2160)/60Hz, 4K(3840 x 2160)/30Hz, 1920 x 1080P/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Product color	Black
Rack mounting	No
LED indicators	Yes
Audio RCA inputs	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Power over Ethernet (PoE) ports quantity	4
HDD capacity	- GB
HDD interface	Serial ATA
Maximum storage capacity	6 TB
Number of HDDs installed	-
Output voltage	48 V
Power consumption (max)	10 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	240 mm
Width	315 mm
Height	48 mm
Weight	1000 g
