Congure Arming Schedule
Steps
1.
Select Arming Schedule.
2.
Choose one day of a week and set the
me segment. Up to eight me periods can be set within
each day.
Note
Time periods shall not be repeated or overlapped.
Figure 5-8 Set Arming Schedule
3.
Click Apply.
Congure
Alarm Linkage Acon
Alarm linkage acons will be acvated when an alarm or excepon occurs.
Steps
1.
Click Linkage Acon.
2.
Set normal linkage acons, alarm output linkage acons, trigger channel, etc.
Alarm Pop-up Window
The local monitor will pop up the alarming channel image when an alarm is triggered. It
requires to select the alarming channel(s) in Trigger Channel.
Buzzer Alarm
It will trigger a buzzer beep when an alarm is triggered.
Nofy Surveillance Center
The device will send an excepon or alarm signal to the remote client soware when an
alarm is triggered.
Send Email
Network Video Recorder User Manual
29

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7608NXI-K2 and is the answer not in the manual?

HIKVISION DS-7608NXI-K2 Specifications

General IconGeneral
Product colorBlack
Rack capacity1U
Rack mountingYes
Input bandwidth80 Mbit/s
Output bandwidth160 Mbit/s
Maximum frame rate30 fps
Maximum resolution3840 x 2160 pixels
Alarm input channels4
Video input channels8 channels
Alarm output channels1
Supported resolutions12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Audio formats supportedG.711 A-law, G.711 μ-law, G.722, AAC, G.726
Video formats supportedH.264, H.264+, H.265, H.265+
Wi-FiNo
HDD capacity10000 GB
HDD interfaceSATA
Maximum storage capacity20 TB
Number of HDDs installed0
Number of HDDs supported2
Networking standardsIEEE 802.3af, IEEE 802.3at
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 1000, 100 Mbit/s
Ethernet LAN (RJ-45) ports9
Supported network protocolsTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
Power over Ethernet (PoE) ports quantity8
Output current2.5 A
Output voltage48 V
Power consumption (typical)15 W
Total Power over Ethernet (PoE) budget80 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
Sustainability certificatesFederal Communications Commission (FCC), CE
Weight and Dimensions IconWeight and Dimensions
Depth315 mm
Width385 mm
Height52 mm
Weight3000 g
