HIKVISION DS-K3BC430LX-868 - 4.3.2 Lane Control Board Terminal Description; 4.3.3 Access Control Board Terminal Description (Optional)

Figure 4-2 General Wiring
Note
●
It is recommended to use Hikvision matched distribuon
cabinet (sold separately) to covert the AC mains power to 24 V.
●
The ① and ② refer to the two sides of a same board.
●
Barrier opens at the entrance/exit: connect to BTN1/BTN2 and
GND.
4.3.2 Lane Control Board Terminal Descripon
The lane control board contains indicator board interface,
interconnecng interface, access control board interface, re
input interface, exit buon interface, 12 VDC output interface, 24
VDC input interface, communicaon interface, encoder interface,
power supply interface for motor, supercapacitor interface, brake
interface, and tamper interface.
The picture displayed below is the lane control board diagram.
Figure 4-3 Lane Control Board
4.3.3 Access Control Board Terminal
Descripon
(Oponal)
9
